JONSSON L 120-330 TRACKED DOUBLE CRUSHER
JONSSON L 120-330 TRACKED DOUBLE CRUSHER
The Jonsson L 120-330 combines a robust and compact design with impressive capacity and a proven concept. The combination of the two Nordberg® C120 and GP330 crushers has met the expectations of our customers.
Double electric-powered crushers provide lower operating and maintenance costs, while also making L 120-330 gentler on the environment. With two crushers on the same chassis, reloading is avoided and the crushing plant requires less space for setting up.
MACHINE SPECIFICATIONS
| Total Weight: | approx. 133 ton |
| Engine | CAT®, 403 kW |
| Feed opening | 1 300 x 1000mm |
| Machine weight | 103 000kg |
Total Weight:
Crusher:
Crusher Opening:
Feeder and Pre-screen:
Feeder and Pre-screen:
Feeder:
Production Screen:
Electric Motor:
Crusher:
Crusher Opening:
Feeder and Pre-screen:
Feeder and Pre-screen:
Feeder:
Production Screen:
Electric Motor:
approx. 133 ton
Nordberg® C120 and Nordberg® GP330
1200 x 870 mm < 225 mm
Jonsson JF 1030, Jonsson JS 1214/3G
Jonsson JF 1050, Jonsson JS 0812/2
Jonsson JF 0926
Jonsson JS 1632/3
160 kW / 315 kW
Nordberg® C120 and Nordberg® GP330
1200 x 870 mm < 225 mm
Jonsson JF 1030, Jonsson JS 1214/3G
Jonsson JF 1050, Jonsson JS 0812/2
Jonsson JF 0926
Jonsson JS 1632/3
160 kW / 315 kW
