IC50 HSI HORIZONTAL SHAFT IMPACT CRUSHER

IC50 Horizontal Shaft Impact Crusher

The Pilot Modular IC50 Horizontal Shaft Impact Crusher is a versatile, high performance, impact crusher for primary and secondary crushing applications. It is supplied complete, ready to run and is mounted on a skid-frame with maintenance platform and access ladder.

The crusher is equipped with a heavy-duty, fixed hammer rotor, three high chrome blow-bars, 400BHN liners and impact plates and features an adjustable impact apron, with oversize and tramp release. It has a split and hinged upper housing to provide ease of opening for maintenance. Application dependent, it can operate at speeds between 682 – 966 rpm and can handle feed material up to 300mm in soft rock and 100mm in hard rock applications.

pilot modular

Product Downloads

Download Brochure
50 MTPH icon
energy efficient icon
High Reduction icon

Product Features

IC50 HSI HORIZONTAL SHAFT IMPACT CRUSHER
icon

The IC50 is engineered to deliver excellent reduction ratios, producing consistent, well-shaped aggregates from feed material with minimal passes.

icon

Constructed with heavy-duty components and wear-resistant materials, ensuring reliable operation and durability even in demanding conditions.

icon

The hydraulic adjustment system allows for easy setting of the crusher’s curtains to fine-tune product size and control the end-product grading.

icon

The adjustable impact apron optimises product size, retains oversize material, and safely releases tramp material, ensuring efficient crushing and protection across soft to medium-hard rock, concrete recycling, and asphalt applications.

icon

The three rotor speeds (680 – 970 rpm) allows operators to adjust crushing intensity for optimal product gradation, throughput, and cubicity across soft to medium-hard materials like concrete, asphalt, and aggregates.

icon

Heavy-duty galvanised skid frame with maintenance platform Handrails, safety guards and cat ladder

Extended Benefits

01Improved Product Quality

The IC50 produces a high-quality, cubical end product that meets stringent specifications for road base, concrete, and asphalt applications—reducing the need for additional shaping or screening.

02Lower Operating Costs

By combining efficient crushing action with long-lasting wear parts, the IC50 helps lower overall operating costs through reduced fuel usage and extended maintenance intervals.

03Fast and Safe Maintenance Access

Hydraulic access to the rotor and blow bars ensures faster maintenance turnaround, enhanced safety, and less downtime, keeping operations running smoothly.

04Flexible Feed Compatibility

Capable of handling a wide range of feed materials and sizes, including recycled concrete and demolition waste, the IC50 supports diverse crushing operations across construction and mining sectors.

05Enhanced Production Control

With adjustable impact curtains and speed settings, operators can tailor the crusher’s output to specific product requirements, enabling better process control and consistent performance.

06Compact Footprint for Easy Integration

The compact design allows the IC50 to be easily integrated into new or existing plant layouts, ideal for operations with limited space or mobile setups.

07Energy-Efficient Performance

Optimised rotor design and efficient power usage deliver high productivity while maintaining economical operational costs.

IC50 HORIZONTAL SHAFT IMPACT CRUSHER
IC50 crusher
IC50 HSI crusher
IC50 HORIZONTAL SHAFT IMPACT CRUSHER
IC50 Crusher
HORIZONTAL SHAFT IMPACT CRUSHER
IMPACT CRUSHER
IC50 crusher
IC50 Impact crusher
IC50 Pilot Modular
IC50 Pilot Modular Crusher
IC50 Pilot Modular HSI crusher
IC50 Pilot Modular
IC50 HSI
IC50 crusher
crusher glass

Product Information

TECHNICAL SPECIFICATIONS
Rotor 600mm diameter x 500mm width

Heavy-duty three hammer rotor

Reversible hammers with four working faces

3 Rotors Speeds (Lo-682, Std-815, Hi-966)

Hammer Types HASI High abrasion, Std Impact

MALI Max abrasion, Low Impact

SAMI Standard abrasion, Max Impact

Crusher Housing Split and hinged upper housing for easy maintenance.

Manual hydraulic opening

Feed chute with rubber curtains

Feed opening 500mm x 470mm

400 Brinell liners and impact plates

Impact Apron Fixed primary and adjustable secondary impact apron with over size and tramp release

Drive 30kW 380V or 525V electric motor

SPB Pulleys and V-belt drive

Feed Size Soft rock up to 300mm

Hard rock up to 100mm

Crusher Capacity Up to 50 tonnes / hr (Application Dependant)

Weight ±2 750 kg
